MAHLE ORIGINAL from 030 87 00: Your selected vehicle
Back to the range of Piston
MAZDA (105 KW / 143 PS) MAHLE ORIGINAL 030 87 00
BT-50 (CD, UN) 2.5 MRZ-CD 4x4 (UNY0W3) MAHLE ORIGINAL 4009026549049
MAZDA BT-50 (CD, UN)
2.5 MRZ-CD 4x4 (UNY0W3) (105 kW / 143 hp)
Select vehicle
Brand
Brand
1
Model
Model
2
Motor type
Motor type
3
Car parts catalog:
MAZDA BT-50 (CD, UN) 2.5 MRZ-CD 4x4 (UNY0W3)
  • Air conditioning
  • Bearings
  • Belts, chains, rollers
  • Body
  • Brakes
  • Clutch
  • Damping
  • Drive shaft and cv joint
  • Electrics
  • Engine
  • Engine cooling system
  • Exhaust
  • Filters
  • Fuel supply system
  • Gaskets and sealing rings
  • Gearbox
  • Heating and ventilation
  • Ignition and preheating
  • Interior
  • Lighting
  • Oils and fluids
  • Pipes and hoses
  • Propshafts and differentials
  • Repair kits
  • Sensors, relays, control units
  • Steering
  • Suspension
  • Towbar / parts
  • Wiper and washer system
Top Piston manufacturer
Top Engine spare parts
  1. REXBO-car parts catalogue
  2. Piston car
  3. Piston to cylinder 3, to cylinder 4, for cylinder 3-4, with piston ring carrier, with cooling duct
MAHLE ORIGINAL Piston buy cheap at Rexbo
Piston to cylinder 3, to cylinder 4, for cylinder 3-4, with piston ring carrier, with cooling duct MAHLE ORIGINAL 4009026549049

MAHLE ORIGINAL 030 87 00 Piston to cylinder 3, to cylinder 4, for cylinder 3-4, with piston ring carrier, with cooling duct
Article number: 030 87 00

Piston 4009026549049: rating
Reviews (0)
  • Standard Size [STD]:
  • Fitting Position: to cylinder 3, to cylinder 4, for cylinder 3-4
  • Cylinder Bore [mm]: 79,51
  • Length [mm]: 69,8
  • Compression Height [mm]: 45,8
  • Bolt Length [mm]: 66,0
  • Bolt Head Diameter [mm]: 26,0
  • Recess Depth 1 [mm]: 17,5
  • Recess Diameter [mm]: 38,0
  • Valve Pocket Depth 1 [mm]: 1,15
  • Valve Pocket Depth 2 [mm]: 1,15
  • Machined: with cut-out for oil jet
  • Surface: Coated
  • Supplementary Article / Supplementary Info Info 2: with piston ring carrier, with cooling duct
  • Top Land Height [mm]: 12
  • Production Number: 79 L 79
  • Component Number: 1. R 1.75 CrK, 2. M 2.0 IFU, 3. DSF 3.0 Cr
  • Piston Clearance [mm]: 0,07
  • Packaging height [cm]: 12,80
  • Net Weight [g]: 880
  • Packaging length [cm]: 9,5
  • Packaging width [cm]: 9,50
  • Condition: New
£ 104,91
incl. 20% VAT ,
delivery costs
In stock
- +
Add to basket
Facebook
Product details
  • Recess Depth 1 [mm]: 17,5
  • Top Land Height [mm]: 12
  • Valve Pocket Depth 2 [mm]: 1,15
  • Valve Pocket Depth 1 [mm]: 1,15
  • Component Number: 1. 55 N0
  • Surface: Coated
  • Machined: with cut-out for oil jet
  • Fitting Position: to cylinder 3
  • Supplementary Article/Supplementary Info: with piston rings
  • Other details
  • Manufacturer: MAHLE ORIGINAL
  • Type: Piston
  • EAN: 4009026549049
MAHLE ORIGINAL 4009026549049

MAHLE ORIGINAL Piston 4009026549049 fits the following vehicles:

Manufacturer/Model/Type Year of Construction Motor Engine code Restriction
AUDI A3 Hatchback (8L1) 1.9 TDI 08.2000 - 05.2003 96KW/130PS ASZ
AUDI A3 Hatchback (8L1) 1.9 TDI quattro 08.2000 - 05.2003 96KW/130PS ASZ
AUDI A4 Avant (8E5, B6) 1.9 TDI 09.2001 - 12.2004 96KW/130PS AVF
AUDI A4 Avant (8E5, B6) 1.9 TDI quattro 11.2001 - 12.2004 96KW/130PS AVF
AUDI A4 Saloon (8E2, B6) 1.9 TDI 11.2000 - 12.2004 96KW/130PS AVF
AUDI A4 Saloon (8E2, B6) 1.9 TDI quattro 11.2001 - 12.2004 96KW/130PS AVF
AUDI A6 Avant (4B5, C5) 1.9 TDI 08.2001 - 01.2005 96KW/130PS AVF
AUDI A6 Saloon (4B2, C5) 1.9 TDI 08.2001 - 01.2005 96KW/130PS AVF
FORD GALAXY (WGR) 1.9 TDI 02.2003 - 05.2006 96KW/130PS ASZ
SEAT Alhambra (7V8, 7V9) 1.9 TDI 11.2002 - 11.2008 96KW/131PS ASZ
SEAT Cordoba Saloon (6L2) 1.9 TDI 10.2002 - 11.2009 96KW/131PS BLT
SEAT Ibiza III Hatchback (6L) 1.9 TDI 02.2002 - 11.2009 96KW/131PS BLT
SEAT Ibiza III Hatchback (6L) 1.9 TDI Cupra R 03.2004 - 02.2008 118KW/160PS BPX
SEAT Ibiza III Hatchback (6L) 1.9 TDI Joya Racer 07.2003 - 06.2004 112KW/152PS ASZ
SEAT Leon Hatchback (1M1) 1.9 TDI 05.2003 - 06.2006 96KW/130PS ASZ
SEAT Leon Hatchback (1M1) 1.9 TDI 09.2000 - 06.2006 110KW/150PS ARL
SEAT Leon Hatchback (1M1) 1.9 TDI Syncro 05.2002 - 06.2006 110KW/150PS ARL
SEAT Toledo II Saloon (1M2) 1.9 TDI 05.2003 - 05.2006 96KW/130PS ASZ
SEAT Toledo II Saloon (1M2) 1.9 TDI 10.2000 - 07.2004 110KW/150PS ARL
SKODA FABIA (6Y2) 1.9 TDI RS 06.2003 - 03.2008 96KW/130PS BLT
SKODA OCTAVIA (1U2) 1.9 TDI 09.2002 - 09.2004 96KW/130PS ASZ
SKODA Octavia I Combi (1U5) 1.9 TDI 09.2002 - 09.2004 96KW/130PS ASZ
SKODA SUPERB (3U4) 1.9 TDI 12.2001 - 03.2008 96KW/130PS AWX
VW Bora Saloon (1J2) 1.9 TDI 11.2000 - 05.2005 96KW/130PS ASZ
VW Bora Saloon (1J2) 1.9 TDI 05.2000 - 05.2005 110KW/150PS ARL
VW Bora Saloon (1J2) 1.9 TDI 4motion 11.2000 - 05.2005 96KW/130PS ASZ
VW Bora Saloon (1J2) 1.9 TDI 4motion 05.2000 - 05.2005 110KW/150PS ARL
VW Bora Variant (1J6) 1.9 TDI 11.2000 - 05.2005 96KW/130PS ASZ
VW Bora Variant (1J6) 1.9 TDI 05.2001 - 05.2005 110KW/150PS ARL
VW Bora Variant (1J6) 1.9 TDI 4motion 11.2000 - 05.2005 96KW/130PS ASZ
VW Bora Variant (1J6) 1.9 TDI 4motion 05.2001 - 05.2005 110KW/150PS ARL
VW California T5 Minibus (7EC, 7EF, 7EG, 7HF) 1.9 TDI 05.2007 - 12.2009 62KW/84PS BRR
VW California T5 Minibus (7EC, 7EF, 7EG, 7HF) 1.9 TDI 05.2007 - 11.2009 63KW/85PS AXC
VW California T5 Minibus (7EC, 7EF, 7EG, 7HF) 1.9 TDI 05.2007 - 11.2009 75KW/102PS BRS
VW California T5 Minibus (7EC, 7EF, 7EG, 7HF) 1.9 TDI 05.2007 - 11.2009 77KW/105PS AXB
VW Golf IV Hatchback (1J1) 1.9 TDI 11.2000 - 06.2005 96KW/130PS ASZ
VW Golf IV Hatchback (1J1) 1.9 TDI 05.2000 - 06.2005 110KW/150PS ARL
VW Golf IV Hatchback (1J1) 1.9 TDI 4motion 11.2000 - 06.2005 96KW/130PS ASZ
VW Golf IV Hatchback (1J1) 1.9 TDI 4motion 02.2000 - 06.2005 110KW/150PS ARL
VW Golf IV Variant (1J5) 1.9 TDI 11.2000 - 06.2006 96KW/130PS ASZ
VW Golf IV Variant (1J5) 1.9 TDI 06.2001 - 06.2006 110KW/150PS ARL
VW Golf IV Variant (1J5) 1.9 TDI 4motion 11.2000 - 06.2006 96KW/130PS ASZ
VW Golf IV Variant (1J5) 1.9 TDI 4motion 05.2002 - 06.2005 110KW/150PS ARL
VW Multivan V (7HM, 7HN, 7HF, 7EF, 7EM, 7EN) 1.9 TDI 01.2006 - 11.2009 62KW/84PS BRR
VW Multivan V (7HM, 7HN, 7HF, 7EF, 7EM, 7EN) 1.9 TDI 04.2003 - 11.2009 63KW/85PS AXC
VW Multivan V (7HM, 7HN, 7HF, 7EF, 7EM, 7EN) 1.9 TDI 06.2006 - 11.2009 75KW/102PS BRS
VW Multivan V (7HM, 7HN, 7HF, 7EF, 7EM, 7EN) 1.9 TDI 04.2003 - 11.2009 77KW/105PS AXB
VW PASSAT (3B3) 1.9 TDI 11.2000 - 05.2005 96KW/130PS AVF
VW PASSAT (3B3) 1.9 TDI 4motion 11.2000 - 05.2005 96KW/130PS AVF
VW PASSAT Variant (3B6) 1.9 TDI 11.2000 - 05.2005 96KW/130PS AVF
VW PASSAT Variant (3B6) 1.9 TDI 4motion 11.2000 - 05.2005 96KW/130PS AVF
VW POLO (9N_) 1.9 TDI 11.2003 - 11.2009 96KW/130PS ASZ
VW SHARAN (7M8, 7M9, 7M6) 1.9 TDI 11.2002 - 03.2010 96KW/130PS ASZ
VW Sharan VAN (7M) 1.9 TDI (7M9) 11.2002 - 05.2003 96KW/131PS ASZ
VW Transporter V Minibus (7HB, 7HJ, 7EB, 7EJ, 7EF, 7EG, 7HF, 7EC) 1.9 TDI 01.2006 - 11.2009 62KW/84PS BRR
VW Transporter V Minibus (7HB, 7HJ, 7EB, 7EJ, 7EF, 7EG, 7HF, 7EC) 1.9 TDI 04.2003 - 11.2009 63KW/85PS AXC
VW Transporter V Minibus (7HB, 7HJ, 7EB, 7EJ, 7EF, 7EG, 7HF, 7EC) 1.9 TDI 06.2006 - 11.2009 75KW/102PS BRS
VW Transporter V Minibus (7HB, 7HJ, 7EB, 7EJ, 7EF, 7EG, 7HF, 7EC) 1.9 TDI 04.2003 - 11.2009 77KW/105PS AXB
VW Transporter V Platform / Chassis (7JD, 7JE, 7JL, 7JY, 7JZ, 7FD) 1.9 TDI 01.2006 - 11.2009 62KW/84PS BRR
VW Transporter V Platform / Chassis (7JD, 7JE, 7JL, 7JY, 7JZ, 7FD) 1.9 TDI 04.2003 - 11.2009 63KW/85PS AXC
VW Transporter V Platform / Chassis (7JD, 7JE, 7JL, 7JY, 7JZ, 7FD) 1.9 TDI 06.2006 - 11.2009 75KW/102PS BRS
VW Transporter V Platform / Chassis (7JD, 7JE, 7JL, 7JY, 7JZ, 7FD) 1.9 TDI 04.2003 - 11.2009 77KW/105PS AXB
VW Transporter V Van (7HA, 7HH, 7EA, 7EH) 1.9 TDI 01.2006 - 11.2009 62KW/84PS BRR
VW Transporter V Van (7HA, 7HH, 7EA, 7EH) 1.9 TDI 04.2003 - 11.2009 63KW/85PS AXC
VW Transporter V Van (7HA, 7HH, 7EA, 7EH) 1.9 TDI 06.2006 - 11.2009 75KW/102PS BRS
VW Transporter V Van (7HA, 7HH, 7EA, 7EH) 1.9 TDI 04.2003 - 11.2009 77KW/105PS AXB
OEM numbers
Reference number(s) OEM:
Manufacturer OE number
AUDI 038107065CJ
AUDI 038107065EM
AUDI 038107065EP
AUDI 038107065FR
AUDI 038107065GK
AUDI 038107065GM
AUDI 038107101CB
AUDI 38107065EM
AUDI 38107065GM
CUPRA 038107065CJ
CUPRA 038107065EM
CUPRA 038107065EP
CUPRA 038107065FR
CUPRA 038107065GK
CUPRA 038107065GM
CUPRA 038107101CB
CUPRA 38107065EM
CUPRA 38107065GM
VAG 038107065CJ
VAG 038107065EM
VAG 038107065EP
VAG 038107065FR
VAG 038107065GK
VAG 038107065GM
VAG 038107101CB
VAG 38107065EM
VAG 38107065GM
VW 038107065CJ
VW 038107065EM
VW 038107065EP
VW 038107065FR
VW 038107065GK
VW 038107065GM
VW 038107101CB
VW 38107065EM
VW 38107065GM
The following products are also suitable for the specified OE-number:
Piston manufacturer
MAHLE ORIGINAL 030 87 00
KOLBENSCHMIDT 99471600
IPSA PI001300
NÜRAL 87-114900-46
ET ENGINETEAM PM001900
NÜRAL 87-114900-35
NE 7150490000
ENGITECH ENT050044 STD
