MAHLE ORIGINAL from 021 PI 00124 000: Your selected vehicle
Back to the range of Piston
CITROËN (115 KW / 156 PS) MAHLE ORIGINAL 021 PI 00124 000
C5 III Estate (RW_) 1.6 THP MAHLE ORIGINAL 4057635176101
CITROËN C5 III Estate (RW_)
1.6 THP (115 kW / 156 hp)
Select vehicle
Brand
Brand
1
Model
Model
2
Motor type
Motor type
3
Car parts catalog:
CITROËN C5 III Estate (RW_) 1.6 THP
  • Air conditioning
  • Bearings
  • Belts, chains, rollers
  • Body
  • Brakes
  • Clutch
  • Damping
  • Drive shaft and cv joint
  • Electrics
  • Engine
  • Engine cooling system
  • Exhaust
  • Filters
  • Fuel supply system
  • Gaskets and sealing rings
  • Gearbox
  • Heating and ventilation
  • Ignition and preheating
  • Interior
  • Lighting
  • Oils and fluids
  • Pipes and hoses
  • Propshafts and differentials
  • Repair kits
  • Sensors, relays, control units
  • Steering
  • Suspension
  • Towbar / parts
  • Wiper and washer system
Top Piston manufacturer
Top Engine spare parts
  1. REXBO-car parts catalogue
  2. Piston car
  3. Piston with piston ring carrier, with cooling duct
MAHLE ORIGINAL Piston buy cheap at Rexbo
Piston with piston ring carrier, with cooling duct MAHLE ORIGINAL 4057635176101

MAHLE ORIGINAL 021 PI 00124 000 Piston with piston ring carrier, with cooling duct
Article number: 021 PI 00124 000

Piston 4057635176101: rating
Reviews (0)
  • Cylinder Bore [mm]: 76
  • Length [mm]: 66
  • Compression Height [mm]: 41,8
  • Bolt Length [mm]: 60
  • Bolt Head Diameter [mm]: 26
  • Recess Depth 1 [mm]: 12,9
  • Recess Diameter [mm]: 49
  • Valve Pocket Depth 1 [mm]: 0,3
  • Valve Pocket Depth 2 [mm]: 0,4
  • Machined: with cut-out for oil jet
  • Surface: Phosphated and graphite-coated
  • Supplementary Article / Supplementary Info Info 2: with piston ring carrier, with cooling duct
  • Top Land Height [mm]: 9
  • Connecting Rod Design: Trapezoidal Connecting Rod
  • Production Number: 76 L 157
  • Component Number: 1. R2.0 IF CrK, 2. M 2.0 IFU, 3. DSF 2.5 N
  • Packaging height [cm]: 12,80
  • Net Weight [g]: 610
  • Packaging length [cm]: 9,5
  • Packaging width [cm]: 9,50
  • Condition: New
£ 71,35
incl. 20% VAT ,
delivery costs
Сurrently out of stock
- +
Add to basket
Facebook
Product details
  • Mechanisch bewerkt: 034
  • Klepdiepte 2 [mm]: 0,4
  • Klepdiepte 1 [mm]: 0,3
  • Komdiameter [mm]: 49
  • Komdiepte 1 [mm]: 12,9
  • Bout-Ø [mm]: 26
  • Boutlengte [mm]: 60
  • Compressiehoogte [mm]: 41,8
  • Lengte [mm]: 66
  • Cilinderboring [mm]: 76
  • Other details
  • Manufacturer: MAHLE ORIGINAL
  • Type: Piston
  • EAN: 4057635176101
MAHLE ORIGINAL 4057635176101

MAHLE ORIGINAL Piston 4057635176101 fits the following vehicles:

Manufacturer/Model/Type Year of Construction Motor Engine code Restriction
NISSAN Kubistar Van (X76) dCi 85 04.2006 - 10.2009 62KW/84PS K9K 276
NISSAN TIIDA Hatchback 1.5 dCi 09.2007 - 12.2011 78KW/106PS K9K
NISSAN TIIDA Saloon (SC11X) 1.5 dCi 01.2007 - 12.2012 76KW/103PS K9K
RENAULT CLIO Grandtour (KR0/1_) 1.5 dCi 08.2010 - 12.2012 65KW/88PS K9K 770
RENAULT CLIO Grandtour (KR0/1_) 1.5 dCi (KR0F) 11.2007 - 12.2012 63KW/86PS K9K 766
RENAULT CLIO Grandtour (KR0/1_) 1.5 dCi (KR0H, KR1S) 02.2008 - 12.2012 78KW/106PS K9K 764
RENAULT CLIO Grandtour (KR0/1_) 1.5 dCi (KR1C, KR1N) 11.2007 - 12.2012 76KW/103PS K9K 772
RENAULT CLIO II (BB0/1/2_, CB0/1/2_) 1.5 dCi 10.2003 - 04.2005 74KW/100PS K9K 712
RENAULT CLIO II (BB0/1/2_, CB0/1/2_) 1.5 dCi (BB3N, CB3N) 02.2007 - 06.2009 62KW/84PS K9K 718
RENAULT Clio III Hatchback (BR0/1, CR0/1) 1.5 dCi 08.2010 - 12.2014 65KW/88PS K9K 766
RENAULT Clio III Hatchback (BR0/1, CR0/1) 1.5 dCi (BR0H, CR0H, CR1S, BR1S) 06.2005 - 12.2014 78KW/106PS K9K 764
RENAULT Clio III Hatchback (BR0/1, CR0/1) 1.5 dCi (BR17, CR17) 06.2005 - 12.2012 63KW/86PS K9K 766
RENAULT Clio III Hatchback (BR0/1, CR0/1) 1.5 dCi (BR1C, CR1C) 06.2005 - 12.2012 76KW/103PS K9K 772
RENAULT Clio III Van (SB_, SR_) 1.5 dCi 06.2005 - 07.2010 63KW/86PS K9K 766
RENAULT Clio III Van (SB_, SR_) 1.5 dCi 10.2005 - 10.2007 78KW/106PS K9K 764
RENAULT Duster (HS_) 1.5 dCi 02.2012 - ... 63KW/85PS K9K 796
RENAULT Fluence (L3_) 1.5 dCi (L30B) 02.2010 - ... 78KW/106PS K9K 832
RENAULT GRAND SCÉNIC II (JM0/1_) 1.5 dCi 06.2006 - 11.2008 76KW/103PS K9K 734
RENAULT GRAND SCÉNIC II (JM0/1_) 1.5 dCi (JM02, JM13) 04.2004 - 11.2008 74KW/101PS K9K 728
RENAULT GRAND SCÉNIC II (JM0/1_) 1.5 dCi (JM1E) 05.2005 - 01.2009 78KW/106PS K9K 732
RENAULT GRAND SCÉNIC III (JZ0/1_) 1.5 dCi 02.2009 - 09.2016 78KW/106PS K9K 832
RENAULT KANGOO (KC0/1_) 1.5 dCi 06.2005 - ... 62KW/84PS K9K 718
RENAULT KANGOO / GRAND KANGOO (KW0/1_) 1.5 dCi 02.2008 - ... 78KW/106PS K9K 804
RENAULT KANGOO / GRAND KANGOO (KW0/1_) 1.5 dCi 105 (KW0F) 02.2008 - ... 76KW/103PS K9K 806
RENAULT KANGOO / GRAND KANGOO (KW0/1_) 1.5 dCi 110 (KW0C, KW0H) 09.2010 - ... 80KW/110PS K9K 816
RENAULT KANGOO / GRAND KANGOO (KW0/1_) 1.5 dCi 70 (KW0V, KW0A) 02.2008 - ... 50KW/68PS K9K 800
RENAULT KANGOO / GRAND KANGOO (KW0/1_) 1.5 dCi 85 (KW0K, KW0L, KW0B) 02.2008 - ... 63KW/86PS K9K 812
RENAULT KANGOO BE BOP (KW0/1_) 1.5 dCi 06.2009 - ... 80KW/110PS K9K 804
RENAULT KANGOO BE BOP (KW0/1_) 1.5 dCi (KW0F) 02.2009 - 12.2012 76KW/103PS K9K 806
RENAULT KANGOO BE BOP (KW0/1_) 1.5 dCi 75 09.2010 - ... 55KW/75PS K9K 802
RENAULT KANGOO Express (FC0/1_) 1.5 dCi (FC1G) 06.2005 - ... 62KW/84PS K9K 718
RENAULT KANGOO Express (FW0/1_) 1.5 dCi 105 (FW0F) 02.2008 - ... 76KW/103PS K9K 806
RENAULT KANGOO Express (FW0/1_) 1.5 dCi 110 (FW0C, FW0H) 09.2010 - ... 80KW/109PS K9K 816
RENAULT KANGOO Express (FW0/1_) 1.5 dCi 85 (FW0K, FW0L, FW0B) 02.2008 - ... 63KW/86PS K9K 812
RENAULT LAGUNA III (BT0/1) 1.5 dCi (BT00, BT0A, BT0T, BT1J) 10.2007 - 12.2015 81KW/110PS K9K 780
RENAULT LAGUNA III Grandtour (KT0/1) 1.5 dCi (KT0A, KT0R, KT02) 10.2007 - 12.2015 81KW/110PS K9K 780
RENAULT LOGAN I (LS_) 1.5 dCi 02.2008 - 06.2015 63KW/86PS K9K 796
RENAULT LOGAN I Estate (KS_) 1.5 dCi 02.2008 - 06.2015 63KW/86PS K9K 796
RENAULT MEGANE CC (EZ0/1_) 1.5 dCi (EZ0B, EZ07) 11.2013 - 08.2015 78KW/106PS K9K 832
RENAULT MEGANE II (BM0/1_, CM0/1_) 1.5 dCi (BM02, BM13, BM2A, CM02, CM13) 10.2003 - 02.2008 74KW/101PS K9K 728
RENAULT MEGANE II (BM0/1_, CM0/1_) 1.5 dCi (BM16, CM16) 01.2007 - 03.2009 76KW/103PS K9K 734
RENAULT MEGANE II (BM0/1_, CM0/1_) 1.5 dCi (BM1E, CM1E) 05.2005 - 06.2008 78KW/106PS K9K 732
RENAULT MEGANE II (BM0/1_, CM0/1_) 1.5 dCi (BM1F, CM1F) 05.2005 - 02.2008 63KW/86PS K9K 724
RENAULT MEGANE II Box Body / Estate (KM_) 1.5 dCi (KM02) 08.2003 - 07.2009 74KW/101PS K9K 728
RENAULT MEGANE II Box Body / Estate (KM_) 1.5 dCi (KM1E) 08.2003 - 07.2009 78KW/106PS K9K 732
RENAULT MEGANE II Box Body / Estate (KM_) 1.5 dCi (KM1F) 05.2005 - 07.2009 63KW/86PS K9K 724
RENAULT Megane II Box Body / Hatchback (KM0/2_) 1.5 dCi 04.2005 - 02.2008 63KW/86PS K9K 724
RENAULT Megane II Box Body / Hatchback (KM0/2_) 1.5 dCi 08.2003 - 02.2008 74KW/101PS K9K 728
RENAULT Megane II Box Body / Hatchback (KM0/2_) 1.5 dCi 01.2007 - 03.2009 76KW/103PS K9K 734
RENAULT Megane II Box Body / Hatchback (KM0/2_) 1.5 dCi 05.2005 - 02.2008 78KW/106PS K9K 732
RENAULT MEGANE II Coupé-Cabriolet (EM0/1_) 1.5 dCi (EM16) 01.2007 - 06.2009 76KW/103PS K9K 734
RENAULT MEGANE II Coupé-Cabriolet (EM0/1_) 1.5 dCi (EM1E) 03.2006 - 01.2009 78KW/106PS K9K 732
RENAULT MEGANE II Estate (KM0/1_) 1.5 dCi (KM02, KM13) 02.2004 - 03.2006 74KW/101PS K9K 728
RENAULT MEGANE II Estate (KM0/1_) 1.5 dCi (KM16) 01.2007 - 07.2009 76KW/103PS K9K 734
RENAULT MEGANE II Estate (KM0/1_) 1.5 dCi (KM16, KM1E) 05.2005 - 06.2008 78KW/106PS K9K 732
RENAULT MEGANE II Estate (KM0/1_) 1.5 dCi (KM1F) 05.2005 - 07.2009 63KW/86PS K9K 724
RENAULT MEGANE II Saloon (LM0/1_) 1.5 dCi (LM02, LM13, LM2A) 02.2004 - 12.2010 74KW/101PS K9K 728
RENAULT MEGANE II Saloon (LM0/1_) 1.5 dCi (LM16) 10.2003 - 12.2010 76KW/103PS K9K 734
RENAULT MEGANE II Saloon (LM0/1_) 1.5 dCi (LM1E) 05.2005 - 12.2010 78KW/106PS K9K 732
RENAULT MEGANE II Saloon (LM0/1_) 1.5 dCi (LM1F) 05.2005 - 12.2010 63KW/86PS K9K 724
RENAULT MEGANE III Coupe (DZ0/1_) 1.5 dCi (DZ0B) 02.2009 - 08.2015 78KW/106PS K9K 832
RENAULT MEGANE III Grandtour (KZ0/1) 1.5 dCi (KZ1M, KZ1W, KZ0R) 02.2009 - 08.2015 78KW/106PS K9K 832
RENAULT Megane III Hatchback (BZ0/1_) 1.5 dCi 02.2009 - 01.2016 78KW/106PS K9K 832
RENAULT MODUS / GRAND MODUS (F/JP0_) 1.5 dCi (FP0F, JP0F) 12.2004 - ... 63KW/86PS K9K 766
RENAULT MODUS / GRAND MODUS (F/JP0_) 1.5 dCi (JP02) 05.2007 - ... 76KW/103PS K9K 772
RENAULT MODUS / GRAND MODUS (F/JP0_) 1.5 dCi (JP0G, JP0H) 05.2005 - ... 78KW/106PS K9K 764
RENAULT Scala (LJM_) 1.5 dCi 09.2012 - 10.2017 63KW/86PS K9K 766
RENAULT SCÉNIC II (JM0/1_) 1.5 dCi (JM02, JM13) 11.2003 - 08.2005 74KW/101PS K9K 728
RENAULT SCÉNIC II (JM0/1_) 1.5 dCi (JM16) 01.2007 - 11.2008 76KW/103PS K9K 734
RENAULT SCÉNIC II (JM0/1_) 1.5 dCi (JM1E, JM16) 05.2005 - 11.2008 78KW/106PS K9K 734
RENAULT SCÉNIC II (JM0/1_) 1.5 dCi (JM1F) 05.2005 - 11.2008 63KW/86PS K9K 724
RENAULT Scénic III (JZ0/1_) 1.5 dCi 02.2009 - 09.2016 78KW/106PS K9K 832
RENAULT Thalia I (LB_) 1.5 dCi 06.2001 - 02.2009 62KW/84PS K9K 718
RENAULT THALIA II (LU1/2_) 1.5 dCi 09.2008 - ... 62KW/85PS K9K 718
RENAULT TWINGO II (CN0_) 1.5 dCi (CN0U) 04.2008 - 09.2014 62KW/84PS K9K 718
DACIA DUSTER 1.5 dCi 04.2010 - 01.2018 63KW/86PS K9K 796
DACIA LOGAN (LS_) 1.5 dCi (LS0W) 09.2007 - 12.2011 63KW/86PS K9K 796
DACIA LOGAN EXPRESS (FS_) 1.5 dCi (FS0W) 03.2009 - ... 63KW/86PS K9K 796
DACIA LOGAN MCV (KS_) 1.5 dCi (KS0W) 09.2007 - 12.2012 63KW/86PS K9K 796
DACIA LOGAN Pickup (US_) 1.5 dCi (US0W) 03.2008 - ... 63KW/86PS K9K 796
DACIA SANDERO 1.5 dCi 11.2008 - ... 63KW/86PS K9K 796
OEM numbers
Reference number(s) OEM:
Manufacturer OE number
FEDERAL 8712340020
FEDERAL 8712340062
RENAULT 120A17699R
RENAULT 120A18456R
RENAULT 7701475354
RENAULT 7701476563
The following products are also suitable for the specified OE-number:
Piston manufacturer
NÜRAL 87-123400-20
MAHLE ORIGINAL 021 PI 00122 000
MAHLE ORIGINAL 021 PI 00124 000
KOLBENSCHMIDT 41068600
KOLBENSCHMIDT 41069600
