BENDIX Braking from BDS1703HC: Your selected vehicle
Back to the range of Brake discs
TOYOTA (110 KW / 150 PS) BENDIX Braking BDS1703HC
Avensis Verso (_M2_) 2.0 VVT-i (ACM20_) BENDIX Braking 4065586146302
TOYOTA Avensis Verso (_M2_)
2.0 VVT-i (ACM20_) (110 kW / 150 hp)
Select vehicle
Brand
Brand
1
Model
Model
2
Motor type
Motor type
3
Car parts catalog:
TOYOTA Avensis Verso (_M2_) 2.0 VVT-i (ACM20_)
  • Air conditioning
  • Bearings
  • Belts, chains, rollers
  • Body
  • Brakes
  • Clutch
  • Damping
  • Drive shaft and cv joint
  • Electrics
  • Engine
  • Engine cooling system
  • Exhaust
  • Filters
  • Fuel supply system
  • Gaskets and sealing rings
  • Gearbox
  • Heating and ventilation
  • Ignition and preheating
  • Interior
  • Lighting
  • Oils and fluids
  • Pipes and hoses
  • Propshafts and differentials
  • Repair kits
  • Sensors, relays, control units
  • Steering
  • Suspension
  • Towbar / parts
  • Wiper and washer system
Top Brake discs manufacturer
Top Brakes spare parts
  1. REXBO-car parts catalogue
  2. Brake discs car
  3. Brake disc Ø: 355mm, internally vented, Ø: 355mm, Coated, without wheel hub, without wheel bearing, without wheel studs
BENDIX Braking Brake discs buy cheap at Rexbo
Brake disc Ø: 355mm, internally vented, Ø: 355mm, Coated, without wheel hub, without wheel bearing, without wheel studs BENDIX Braking 4065586146302

BENDIX Braking BDS1703HC Brake disc Ø: 355mm, internally vented, Ø: 355mm, Coated, without wheel hub, without wheel bearing, without wheel studs
Article number: BDS1703HC

Brake disc 4065586146302: rating
Reviews (0)
  • Diameter [mm]: 355
  • Brake Disc Type: internally vented
  • Centering Diameter [mm]: 71
  • Hole Arrangement/Number: 05/05
  • Wheel Bolt Bore Diameter [mm]: 14,2
  • Bolt Hole Circle Ø [mm]: 108
  • Brake Disc Thickness [mm]: 32
  • Surface: Coated
  • Minimum thickness [mm]: 30
  • Inner Diameter [mm]: 160,7
  • Height [mm]: 48,2
  • Weight [kg]: 12,4
  • Machining: High-carbon
  • Supplementary Article / Supplementary Info Info 2: without wheel hub, without wheel bearing, without wheel studs
  • Packaging length [cm]: 36,8
  • Packaging width [cm]: 36,8
  • Packaging height [cm]: 7
  • Condition: New
£ 95,84
incl. 20% VAT ,
delivery costs
Сurrently out of stock
- +
Add to basket
Facebook
Product details
  • Binnendiameter [mm]: 160,7
  • Oppervlakte: 037
  • Verwerking: 009
  • Minimale dikte [mm]: 30
  • Hoogte [mm]: 48,2
  • Remschijfdikte [mm]: 32
  • Buitendiameter [mm]: 355
  • Remschijftype: 003
  • Other details
  • Manufacturer: BENDIX Braking
  • Type: Brake disc
  • EAN: 4065586146302
BENDIX Braking 4065586146302

BENDIX Braking Brake disc 4065586146302 fits the following vehicles:

Manufacturer/Model/Type Year of Construction Motor Engine code Restriction
JAGUAR F-Type Convertible (X152) 3.0 SCV6 10.2012 - ... 250KW/340PS 306PS(AJ126)
JAGUAR F-Type Convertible (X152) 3.0 SCV6 S 10.2012 - ... 280KW/380PS 306PS(AJ126)
JAGUAR F-Type Convertible (X152) 3.0 SCV6 S AWD 12.2014 - ... 280KW/380PS 306PS(AJ126)
JAGUAR F-Type Convertible (X152) 5.0 SCV8 R 10.2013 - ... 405KW/551PS 508PS(AJ133)
JAGUAR F-Type Convertible (X152) 5.0 SCV8 R AWD 12.2014 - ... 405KW/551PS 508PS(AJ133)
JAGUAR F-Type Convertible (X152) 5.0 SCV8 S 10.2012 - ... 364KW/495PS 508PS(AJ133)
JAGUAR F-Type Convertible (X152) 5.0 SCV8 SVR 05.2015 - ... 423KW/575PS 508PS(AJ133)
JAGUAR F-Type Convertible (X152) 5.0 SCV8 SVR / SCV8 P575 R AWD 12.2015 - ... 423KW/575PS 508PS(AJ133)
JAGUAR F-Type Coupe (X152) 3.0 SCV6 10.2013 - ... 250KW/340PS 306PS(AJ126)
JAGUAR F-Type Coupe (X152) 3.0 SCV6 S 10.2013 - ... 280KW/380PS 306PS(AJ126)
JAGUAR F-Type Coupe (X152) 3.0 SCV6 S AWD 12.2014 - ... 280KW/380PS 306PS(AJ126)
JAGUAR F-Type Coupe (X152) 5.0 SCV8 R 10.2013 - ... 405KW/551PS 508PS(AJ133)
JAGUAR F-Type Coupe (X152) 5.0 SCV8 R AWD 12.2014 - ... 405KW/551PS 508PS(AJ133)
JAGUAR F-Type Coupe (X152) 5.0 SCV8 S 10.2013 - 12.2015 364KW/495PS 508PS(AJ133)
JAGUAR F-Type Coupe (X152) 5.0 SCV8 SVR / SCV8 P575 R 12.2015 - ... 423KW/575PS 508PS(AJ133)
JAGUAR S-Type (X200) 4.2 Supercharged 11.2001 - 12.2008 298KW/405PS AJ36
JAGUAR S-Type (X200) R 4,2 V8 04.2002 - 10.2007 291KW/396PS 1B(AJ36)
JAGUAR XF (_J05_, CC9) 2.0 06.2012 - 04.2015 177KW/241PS 204PT(GTDI)
JAGUAR XF (_J05_, CC9) 2.0 06.2012 - 04.2015 179KW/243PS 204PT(GTDI)
JAGUAR XF (_J05_, CC9) 2.2 D 04.2011 - 04.2015 120KW/163PS 224DT(DW12C)
JAGUAR XF (_J05_, CC9) 2.2 D 05.2011 - 04.2015 140KW/190PS 224DT(DW12C)
JAGUAR XF (_J05_, CC9) 2.2 D 03.2012 - 04.2015 147KW/200PS 224DT(DW12C)
JAGUAR XF (_J05_, CC9) 2.7 D 03.2008 - 04.2015 152KW/207PS 7G(AJTDV6)
JAGUAR XF (_J05_, CC9) 3.0 03.2008 - 04.2015 175KW/238PS FG(AJV6)
JAGUAR XF (_J05_, CC9) 3.0 03.2012 - 04.2015 250KW/340PS 306PS(AJ126)
JAGUAR XF (_J05_, CC9) 3.0 AWD 10.2012 - 04.2015 250KW/340PS 306PS(AJ126)
JAGUAR XF (_J05_, CC9) 3.0 D 03.2009 - 04.2015 155KW/211PS 306DT(AJTDV6)
JAGUAR XF (_J05_, CC9) 3.0 D 03.2009 - 04.2015 177KW/241PS 306DT(AJTDV6)
JAGUAR XF (_J05_, CC9) 3.0 D 03.2009 - 04.2015 202KW/275PS 306DT(AJTDV6)
JAGUAR XF (_J05_, CC9) 4.2 03.2008 - 04.2015 219KW/298PS SV82G
JAGUAR XF (_J05_, CC9) 4.2 Kompressor 03.2008 - 04.2015 306KW/416PS SV8TS
JAGUAR XF (_J05_, CC9) 5.0 03.2009 - 04.2015 283KW/385PS 508PN(AJ133)
JAGUAR XF Sportbrake (X250) 2.0 T 08.2013 - 12.2015 177KW/240PS 204PT(GTDI)
JAGUAR XF Sportbrake (X250) 3.0 D 09.2012 - 04.2014 177KW/241PS 306DT(AJTDV6)
JAGUAR XF Sportbrake (X250) 3.0 D 09.2012 - 04.2014 202KW/275PS 306DT(AJTDV6)
JAGUAR XJ (X35_, _J12_, _J24_) 2.0 Ti4 05.2012 - 12.2019 177KW/241PS 204PT(GTDI)
JAGUAR XJ (X35_, _J12_, _J24_) 3.0 SCV6 03.2012 - 12.2019 250KW/340PS 306PS(AJ126)
JAGUAR XJ (X35_, _J12_, _J24_) 3.0 SCV6 AWD 10.2012 - 12.2019 250KW/340PS 306PS(AJ126)
JAGUAR XJ (X35_, _J12_, _J24_) 3.0 SDV6 10.2009 - 04.2016 202KW/275PS 306DT(AJTDV6)
JAGUAR XJ (X35_, _J12_, _J24_) 3.0 SDV6 04.2015 - 12.2019 221KW/300PS 306DT(AJTDV6)
JAGUAR XJ (X35_, _J12_, _J24_) 3.0 V6 01.2011 - 12.2019 175KW/238PS AJV6(3.0 Liter)
JAGUAR XJ (X35_, _J12_, _J24_) 5.0 V8 10.2009 - 12.2019 283KW/385PS 508PN(AJ133)
JAGUAR XJ Saloon (X350, X358) R 4.2 03.2003 - 03.2009 291KW/395PS TB(AJ33SC)
JAGUAR XJ Saloon (X350, X358) R 4.2 07.2003 - 03.2009 298KW/405PS TB(AJ33SC)
JAGUAR XK Convertible (X150) 4.2 XKR 03.2006 - 07.2014 306KW/416PS SV8TS
JAGUAR XK Convertible (X150) 4.2 XKR 08.2006 - 07.2014 313KW/426PS SV8TS
JAGUAR XK Convertible (X150) 5.0 V8 01.2009 - 07.2014 283KW/385PS 508PN(AJ133)
JAGUAR XK Coupe (X150) 4.2 XKR 03.2006 - 07.2014 291KW/396PS AJ36
JAGUAR XK Coupe (X150) 4.2 XKR 03.2006 - 07.2014 306KW/416PS SV8TS
JAGUAR XK Coupe (X150) 4.2 XKR 08.2006 - 07.2014 313KW/426PS SV8TS
JAGUAR XK Coupe (X150) 5.0 V8 01.2009 - 07.2014 283KW/385PS 508PN(AJ133) Construction Year from 01/2010
JAGUAR XK Coupe (X150) 5.0 XKR 09.2010 - 07.2014 390KW/530PS 508PS(AJ133)
OEM numbers
Reference number(s) OEM:
Manufacturer OE number
JAGUAR C2C25337
JAGUAR T2R5939
The following products are also suitable for the specified OE-number:
Brake disc manufacturer
DELPHI BG9071
BOSCH 0 986 479 754
ZIMMERMANN 290.2264.20
TRISCAN 8120 101123C
TRW DF6146S
MINTEX MDC2111
TEXTAR 92186303
A.B.S. 18008
BLUE PRINT ADJ134302
JURID 562692JC
ZIMMERMANN 290.2264.52
STARK SKBD-0023002
NK 311225
RIDEX 82B0852
REMSA 61511.10
BREMBO 09.B556.11
MEYLE 18-83 521 0008/PD
sbs 1815311225
FEBI BILSTEIN 44134
ROADHOUSE 61511.10
HELLA 8DD 355 129-071
HELLA PAGID 8DD 355 129-071
TEXTAR 92186305
SWAG 99 94 4134
QUINTON HAZELL BDC5875
OPEN PARTS BDR2677.20
DELPHI BG9071C
OPTIMAL BS-9170
ABE C3J006ABE
FERODO DDF2107C-1
LPR J1022V
MINTEX MDC2111C
ROTINGER RT 20801-GL
MAGNETI MARELLI 360406127101
JURID 562692JC-1
OPTIMAL BS-9170HC
JP GROUP 5463100600
MAXGEAR 19-3527
MAXGEAR 19-3527SPORT
QUARO QD4276
JAGUAR C2C25337
ASHIKA 60-00-0337
JAPKO 600337
SAMKO J1022V
JAPANPARTS DI-0337C
ASHIKA 60-00-0337C
JAPKO 600337C
BENDIX Braking BDS1703HC
ZIMMERMANN 290.2264.54
ZIMMERMANN 290.2264.55
MAXGEAR 19-4917
MIKODA 1831
MIKODA 1831S
Frankberg 5481FB0033408
Frankberg 5481FB0034121
