MAHLE ORIGINAL Piston buy cheap at Rexbo
Piston to cylinder 1, to cylinder 2, for cylinder 1-2, with piston ring carrier, with cooling duct MAHLE ORIGINAL 2503001468087

MAHLE ORIGINAL 030 86 01 Piston to cylinder 1, to cylinder 2, for cylinder 1-2, with piston ring carrier, with cooling duct
Article number: 030 86 01

Piston 2503001468087: rating
Reviews (0)
  • Fitting Position: to cylinder 1, to cylinder 2, for cylinder 1-2
  • Cylinder Bore [mm]: 79,76
  • Length [mm]: 69,8
  • Compression Height [mm]: 45,8
  • Bolt Length [mm]: 66,0
  • Bolt Head Diameter [mm]: 26,0
  • Recess Depth 1 [mm]: 17,5
  • Recess Diameter [mm]: 38,0
  • Valve Pocket Depth 1 [mm]: 1,15
  • Valve Pocket Depth 2 [mm]: 1,15
  • Machined: with cut-out for oil jet
  • Surface: Coated
  • Supplementary Article / Supplementary Info Info 2: with piston ring carrier, with cooling duct
  • Top Land Height [mm]: 12
  • Production Number: 79 L 79
  • Component Number: 1. R 1.75 CrK, 2. M 2.0 IFU, 3. DSF 3.0 Cr
  • Piston Clearance [mm]: 0,07
  • Packaging height [cm]: 12,80
  • Net Weight [g]: 600
  • Packaging length [cm]: 9,5
  • Packaging width [cm]: 9,50
  • Condition: New
£ 99,19
incl. 20% VAT ,
delivery costs
Сurrently out of stock
- +
Add to basket
Facebook
Product details
  • Top Land Height [mm]: 12
  • for cylinder: 1/2
  • Valve Pocket Depth 2 [mm]: 1,15
  • Valve Pocket Depth 1 [mm]: 1,15
  • Component Number: 1. 55 N1
  • Surface: Coated
  • Machined: with cut-out for oil jet
  • Fitting Position: to cylinder 1
  • Supplementary Article/Supplementary Info: with piston rings
  • Other details
  • Manufacturer: MAHLE ORIGINAL
  • Type: Piston
  • EAN: 2503001468087
MAHLE ORIGINAL 2503001468087

MAHLE ORIGINAL Piston 2503001468087 fits the following vehicles:

Manufacturer/Model/Type Year of Construction Motor Engine code Restriction
AUDI A3 Hatchback (8L1) 1.9 TDI 08.2000 - 05.2003 96KW/130PS ASZ
AUDI A3 Hatchback (8L1) 1.9 TDI quattro 08.2000 - 05.2003 96KW/130PS ASZ
AUDI A4 Avant (8E5, B6) 1.9 TDI 09.2001 - 12.2004 96KW/130PS AVF
AUDI A4 Avant (8E5, B6) 1.9 TDI quattro 11.2001 - 12.2004 96KW/130PS AVF
AUDI A4 Saloon (8E2, B6) 1.9 TDI 11.2000 - 12.2004 96KW/130PS AVF
AUDI A4 Saloon (8E2, B6) 1.9 TDI quattro 11.2001 - 12.2004 96KW/130PS AVF
AUDI A6 Avant (4B5, C5) 1.9 TDI 08.2001 - 01.2005 96KW/130PS AVF
AUDI A6 Saloon (4B2, C5) 1.9 TDI 08.2001 - 01.2005 96KW/130PS AVF
FORD GALAXY (WGR) 1.9 TDI 02.2003 - 05.2006 96KW/130PS ASZ
SEAT Alhambra (7V8, 7V9) 1.9 TDI 11.2002 - 11.2008 96KW/131PS ASZ
SEAT Cordoba Saloon (6L2) 1.9 TDI 10.2002 - 11.2009 96KW/131PS BLT
SEAT Ibiza III Hatchback (6L) 1.9 TDI 02.2002 - 11.2009 96KW/131PS BLT
SEAT Ibiza III Hatchback (6L) 1.9 TDI Cupra R 03.2004 - 02.2008 118KW/160PS BPX
SEAT Ibiza III Hatchback (6L) 1.9 TDI Joya Racer 07.2003 - 06.2004 112KW/152PS ASZ
SEAT Leon Hatchback (1M1) 1.9 TDI 05.2003 - 06.2006 96KW/130PS ASZ
SEAT Leon Hatchback (1M1) 1.9 TDI 09.2000 - 06.2006 110KW/150PS ARL
SEAT Leon Hatchback (1M1) 1.9 TDI Syncro 05.2002 - 06.2006 110KW/150PS ARL
SEAT Toledo II Saloon (1M2) 1.9 TDI 05.2003 - 05.2006 96KW/130PS ASZ
SEAT Toledo II Saloon (1M2) 1.9 TDI 10.2000 - 07.2004 110KW/150PS ARL
SKODA FABIA (6Y2) 1.9 TDI RS 06.2003 - 03.2008 96KW/130PS BLT
SKODA OCTAVIA (1U2) 1.9 TDI 09.2002 - 09.2004 96KW/130PS ASZ
SKODA Octavia I Combi (1U5) 1.9 TDI 09.2002 - 09.2004 96KW/130PS ASZ
SKODA SUPERB (3U4) 1.9 TDI 12.2001 - 03.2008 96KW/130PS AWX
VW Bora Saloon (1J2) 1.9 TDI 11.2000 - 05.2005 96KW/130PS ASZ
VW Bora Saloon (1J2) 1.9 TDI 05.2000 - 05.2005 110KW/150PS ARL
VW Bora Saloon (1J2) 1.9 TDI 4motion 11.2000 - 05.2005 96KW/130PS ASZ
VW Bora Saloon (1J2) 1.9 TDI 4motion 05.2000 - 05.2005 110KW/150PS ARL
VW Bora Variant (1J6) 1.9 TDI 11.2000 - 05.2005 96KW/130PS ASZ
VW Bora Variant (1J6) 1.9 TDI 05.2001 - 05.2005 110KW/150PS ARL
VW Bora Variant (1J6) 1.9 TDI 4motion 11.2000 - 05.2005 96KW/130PS ASZ
VW Bora Variant (1J6) 1.9 TDI 4motion 05.2001 - 05.2005 110KW/150PS ARL
VW California T5 Minibus (7EC, 7EF, 7EG, 7HF) 1.9 TDI 05.2007 - 12.2009 62KW/84PS BRR
VW California T5 Minibus (7EC, 7EF, 7EG, 7HF) 1.9 TDI 05.2007 - 11.2009 63KW/85PS AXC
VW California T5 Minibus (7EC, 7EF, 7EG, 7HF) 1.9 TDI 05.2007 - 11.2009 75KW/102PS BRS
VW California T5 Minibus (7EC, 7EF, 7EG, 7HF) 1.9 TDI 05.2007 - 11.2009 77KW/105PS AXB
VW Golf IV Hatchback (1J1) 1.9 TDI 11.2000 - 06.2005 96KW/130PS ASZ
VW Golf IV Hatchback (1J1) 1.9 TDI 05.2000 - 06.2005 110KW/150PS ARL
VW Golf IV Hatchback (1J1) 1.9 TDI 4motion 11.2000 - 06.2005 96KW/130PS ASZ
VW Golf IV Hatchback (1J1) 1.9 TDI 4motion 02.2000 - 06.2005 110KW/150PS ARL
VW Golf IV Variant (1J5) 1.9 TDI 11.2000 - 06.2006 96KW/130PS ASZ
VW Golf IV Variant (1J5) 1.9 TDI 06.2001 - 06.2006 110KW/150PS ARL
VW Golf IV Variant (1J5) 1.9 TDI 4motion 11.2000 - 06.2006 96KW/130PS ASZ
VW Golf IV Variant (1J5) 1.9 TDI 4motion 05.2002 - 06.2005 110KW/150PS ARL
VW Multivan V (7HM, 7HN, 7HF, 7EF, 7EM, 7EN) 1.9 TDI 01.2006 - 11.2009 62KW/84PS BRR
VW Multivan V (7HM, 7HN, 7HF, 7EF, 7EM, 7EN) 1.9 TDI 04.2003 - 11.2009 63KW/85PS AXC
VW Multivan V (7HM, 7HN, 7HF, 7EF, 7EM, 7EN) 1.9 TDI 06.2006 - 11.2009 75KW/102PS BRS
VW Multivan V (7HM, 7HN, 7HF, 7EF, 7EM, 7EN) 1.9 TDI 04.2003 - 11.2009 77KW/105PS AXB
VW PASSAT (3B3) 1.9 TDI 11.2000 - 05.2005 96KW/130PS AVF
VW PASSAT (3B3) 1.9 TDI 4motion 11.2000 - 05.2005 96KW/130PS AVF
VW PASSAT Variant (3B6) 1.9 TDI 11.2000 - 05.2005 96KW/130PS AVF
VW PASSAT Variant (3B6) 1.9 TDI 4motion 11.2000 - 05.2005 96KW/130PS AVF
VW POLO (9N_) 1.9 TDI 11.2003 - 11.2009 96KW/130PS ASZ
VW SHARAN (7M8, 7M9, 7M6) 1.9 TDI 11.2002 - 03.2010 96KW/130PS ASZ
VW Sharan VAN (7M) 1.9 TDI (7M9) 11.2002 - 05.2003 96KW/131PS ASZ
VW Transporter V Minibus (7HB, 7HJ, 7EB, 7EJ, 7EF, 7EG, 7HF, 7EC) 1.9 TDI 01.2006 - 11.2009 62KW/84PS BRR
VW Transporter V Minibus (7HB, 7HJ, 7EB, 7EJ, 7EF, 7EG, 7HF, 7EC) 1.9 TDI 04.2003 - 11.2009 63KW/85PS AXC
VW Transporter V Minibus (7HB, 7HJ, 7EB, 7EJ, 7EF, 7EG, 7HF, 7EC) 1.9 TDI 06.2006 - 11.2009 75KW/102PS BRS
VW Transporter V Minibus (7HB, 7HJ, 7EB, 7EJ, 7EF, 7EG, 7HF, 7EC) 1.9 TDI 04.2003 - 11.2009 77KW/105PS AXB
VW Transporter V Platform / Chassis (7JD, 7JE, 7JL, 7JY, 7JZ, 7FD) 1.9 TDI 01.2006 - 11.2009 62KW/84PS BRR
VW Transporter V Platform / Chassis (7JD, 7JE, 7JL, 7JY, 7JZ, 7FD) 1.9 TDI 04.2003 - 11.2009 63KW/85PS AXC
VW Transporter V Platform / Chassis (7JD, 7JE, 7JL, 7JY, 7JZ, 7FD) 1.9 TDI 06.2006 - 11.2009 75KW/102PS BRS
VW Transporter V Platform / Chassis (7JD, 7JE, 7JL, 7JY, 7JZ, 7FD) 1.9 TDI 04.2003 - 11.2009 77KW/105PS AXB
VW Transporter V Van (7HA, 7HH, 7EA, 7EH) 1.9 TDI 01.2006 - 11.2009 62KW/84PS BRR
VW Transporter V Van (7HA, 7HH, 7EA, 7EH) 1.9 TDI 04.2003 - 11.2009 63KW/85PS AXC
VW Transporter V Van (7HA, 7HH, 7EA, 7EH) 1.9 TDI 06.2006 - 11.2009 75KW/102PS BRS
VW Transporter V Van (7HA, 7HH, 7EA, 7EH) 1.9 TDI 04.2003 - 11.2009 77KW/105PS AXB
