  3. Piston with piston ring carrier, without cooling duct
MAHLE ORIGINAL Piston buy cheap at Rexbo
Piston with piston ring carrier, without cooling duct MAHLE ORIGINAL 4009026940686

MAHLE ORIGINAL 022 26 10 Piston with piston ring carrier, without cooling duct
Article number: 022 26 10

Piston 4009026940686: rating
Reviews (0)
  • Cylinder Bore [mm]: 89,0
  • Length [mm]: 82,9
  • Compression Height [mm]: 52,83
  • Bolt Length [mm]: 65,0
  • Bolt Head Diameter [mm]: 31,0
  • Recess Depth 1 [mm]: 17,8
  • Recess Diameter [mm]: 43,2
  • Valve Pocket Depth 1 [mm]: 2,12
  • Valve Pocket Depth 2 [mm]: 1,69
  • Machined: with cut-out for oil jet
  • Surface: Coated
  • Supplementary Article / Supplementary Info Info 2: with piston ring carrier, without cooling duct
  • Top Land Height [mm]: 12,2
  • Connecting Rod Design: Trapezoidal Connecting Rod
  • Production Number: 89 L 107
  • Component Number: 1. R2.5 IF Mo P, 2. M 1.75 IFU, 3. DSF 2.5 Cr
  • Piston Clearance [mm]: 0,1
  • Packaging height [cm]: 12,80
  • Net Weight [g]: 735
  • Packaging length [cm]: 9,5
  • Packaging width [cm]: 9,50
  • Condition: New
£ 98,37
incl. 20% VAT ,
delivery costs
Сurrently out of stock
- +
Add to basket
Facebook
Product details
  • Recess Diameter [mm]: 43,2
  • Recess Depth 1 [mm]: 17,8
  • Valve pocket depth 2 [mm]: 1,69
  • Valve pocket depth 1 [mm]: 2,12
  • Compression Height [mm]: 52,83
  • Length [mm]: 82,89
  • Cylinder Bore [mm]: 89,0
  • Supplementary Article/Supplementary Info: 139
  • Other details
  • Manufacturer: MAHLE ORIGINAL
  • Type: Piston
  • EAN: 4009026940686
MAHLE ORIGINAL 4009026940686

MAHLE ORIGINAL Piston 4009026940686 fits the following vehicles:

Manufacturer/Model/Type Year of Construction Motor Engine code Restriction
NISSAN INTERSTAR Box (X70) dCi 100 11.2003 - 03.2006 73KW/99PS G9U 720
NISSAN INTERSTAR Box (X70) dCi 100 04.2006 - ... 74KW/101PS G9U 720
NISSAN INTERSTAR Box (X70) dCi 115 04.2002 - ... 84KW/115PS G9U 720
NISSAN INTERSTAR Bus (X70) dCi 100 11.2003 - 03.2006 73KW/99PS G9U 720
NISSAN INTERSTAR Bus (X70) dCi 115 04.2002 - 08.2006 84KW/115PS G9U 720
NISSAN INTERSTAR Platform/Chassis dCi 100 02.2004 - ... 73KW/99PS G9U 720
NISSAN INTERSTAR Platform/Chassis dCi 115 08.2003 - ... 84KW/115PS G9U 720
NISSAN PRIMASTAR Box (X83) 2.5 dCi 115 09.2008 - ... 84KW/114PS G9U 630
NISSAN PRIMASTAR Box (X83) 2.5 dCi 140 07.2003 - ... 99KW/135PS G9U 730
NISSAN PRIMASTAR Bus (X83) dCi 115 09.2008 - ... 84KW/114PS G9U 630
NISSAN PRIMASTAR Bus (X83) dCi 140 07.2003 - ... 99KW/135PS G9U 730
NISSAN Primastar Platform / Chassis (X83) 2.5 dCi 140 07.2002 - 08.2006 99KW/135PS G9U 730
OPEL Movano Minibus (X70) 2.5 CDTI (JD) 10.2003 - 12.2006 73KW/99PS G9U 754
OPEL Movano Minibus (X70) 2.5 DTI (JD) 10.2001 - ... 84KW/115PS G9U 724
OPEL Movano Platform / Chassis (X70) 2.5 DTi (ED, HD, UD0, UD4) 10.2003 - ... 73KW/99PS G9U 754
OPEL Movano Platform / Chassis (X70) 2.5 DTI (ED, HD, UD0, UD4) 10.2001 - ... 84KW/115PS G9U 724
OPEL Movano Van (X70) 2.5 DTi (FD) 10.2003 - ... 73KW/99PS G9U 754
OPEL Movano Van (X70) 2.5 DTI (FD) 10.2001 - ... 84KW/115PS G9U 724
OPEL Vivaro A Combi (X83) 2.5 DTI (F7, J7, A07) 04.2003 - 03.2010 99KW/135PS G9U 730
OPEL Vivaro A Platform / Chassis (X83) 2.5 DTi 04.2003 - 03.2010 99KW/135PS G9U 730
OPEL Vivaro A Van (X83) 2.5 DTI (F7) 04.2003 - 03.2010 99KW/135PS G9U 730
RENAULT MASTER II Box (FD) 2.5 dCi 08.2006 - 01.2010 74KW/101PS G9U 650
RENAULT MASTER II Box (FD) 2.5 dCi 100 (FD0U, FD0V) 10.2003 - 03.2010 73KW/99PS G9U 754
RENAULT MASTER II Box (FD) 2.5 dCi 120 10.2001 - 09.2007 84KW/115PS G9U 724
RENAULT MASTER II Bus (JD) 2.5 dCi 08.2006 - 01.2010 74KW/101PS G9U 650
RENAULT MASTER II Bus (JD) 2.5 dCi 100 (JDCV) 10.2003 - 01.2010 73KW/99PS G9U 754
RENAULT MASTER II Bus (JD) 2.5 dCi 120 10.2001 - 12.2006 84KW/115PS G9U 724
RENAULT MASTER II Platform/Chassis (ED/HD/UD) 2.5 dCi 08.2006 - 01.2010 74KW/101PS G9U 650
RENAULT MASTER II Platform/Chassis (ED/HD/UD) 2.5 dCi 100 (ED4V, ED8V) 10.2003 - 05.2010 73KW/99PS G9U 754
RENAULT MASTER II Platform/Chassis (ED/HD/UD) 2.5 dCi 120 10.2001 - 05.2010 84KW/115PS G9U 724
RENAULT TRAFIC II Box (FL) 2.5 dCi 135 (FL0D) 05.2003 - 10.2006 99KW/135PS G9U 730
RENAULT TRAFIC II Bus (JL) 2.5 dCi 135 (JL0D) 05.2003 - 10.2006 99KW/135PS G9U 730
RENAULT TRAFIC II Platform/Chassis (EL) 2.5 dCi 135 (EL0D) 03.2001 - 10.2006 99KW/135PS G9U 730
VAUXHALL Movano Mk I (A) Combi (X70) 2.5 CDTI (JD) 10.2001 - 08.2009 74KW/101PS G9U 650
VAUXHALL Movano Mk I (A) Combi (X70) 2.5 DTI (JD) 10.2001 - 08.2009 84KW/115PS G9U 750
VAUXHALL Movano Mk I (A) Van (X70) 2.5 (FD) 11.2003 - 12.2006 73KW/99PS G9U 754
VAUXHALL Movano Mk I (A) Van (X70) 2.5 CDTI (FD) 10.2006 - 12.2010 74KW/101PS G9U 650
VAUXHALL Movano Mk I (A) Van (X70) 2.5 DTI (FD) 10.2001 - 05.2010 84KW/115PS G9U 750
VAUXHALL Movano Mk1 (A) Platform / Chassis (X70) 2.5 CDTI (UD0, ED) 11.2003 - 12.2006 73KW/99PS G9U 754
VAUXHALL Movano Mk1 (A) Platform / Chassis (X70) 2.5 CDTI (UD0, ED) 10.2006 - 12.2010 74KW/101PS G9U 650
VAUXHALL Movano Mk1 (A) Platform / Chassis (X70) 2.5 DTI (ED, UD0) 01.2001 - 12.2006 84KW/115PS G9U 750
VAUXHALL VIVARO Combi (J7) 2.5 DTI 07.2003 - 07.2014 99KW/135PS G9U 730
VAUXHALL Vivaro Platform / Chassis (X83) 2.5 CDTI 04.2003 - 07.2006 99KW/135PS G9U 730
VAUXHALL Vivaro Platform / Chassis (X83) 2.5 CDTI 08.2006 - 07.2014 107KW/146PS G9U 630
VAUXHALL Vivaro Van (X83) 2.5 DTI 07.2003 - 07.2014 99KW/135PS G9U 730
