MAHLE ORIGINAL Piston buy cheap at Rexbo
Piston with piston ring carrier, with cooling duct MAHLE ORIGINAL 04009890183

MAHLE ORIGINAL 009 89 01 Piston with piston ring carrier, with cooling duct
Article number: 009 89 01

Piston 04009890183: rating
Reviews (0)
  • Cylinder Bore [mm]: 94,8
  • Length [mm]: 87,6
  • Compression Height [mm]: 58,75
  • Bolt Length [mm]: 72,0
  • Bolt Head Diameter [mm]: 32,0
  • Recess Depth 1 [mm]: 19,4
  • Recess Diameter [mm]: 39,3
  • Machined: with cut-out for oil jet
  • Surface: Coated
  • Supplementary Article / Supplementary Info Info 2: with piston ring carrier, with cooling duct
  • Top Land Height [mm]: 8,8
  • Connecting Rod Design: Trapezoidal Connecting Rod
  • Production Number: 94 L 65
  • Component Number: 1. T 2.5 CrK, 2. M 2.0 P, 3. DSF 2.5 N
  • Piston Clearance [mm]: 0,08
  • Packaging length [cm]: 11,6
  • Packaging width [cm]: 11,60
  • Net Weight [g]: 1240
  • Packaging height [cm]: 14,30
  • Condition: New
£ 102,77
incl. 20% VAT ,
delivery costs
Сurrently out of stock
- +
Add to basket
Facebook
Product details
  • Recess Depth 1 [mm]: 19,4
  • Surface: Coated
  • Machined: with cut-out for oil jet
  • Supplementary Article/Supplementary Info: with piston rings
  • Other details
  • Manufacturer: MAHLE ORIGINAL
  • Type: Piston
  • EAN: 04009890183
MAHLE ORIGINAL 04009890183

MAHLE ORIGINAL Piston 04009890183 fits the following vehicles:

Manufacturer/Model/Type Year of Construction Motor Engine code Restriction
FIAT DUCATO Box (230L) 2.8 TD 4x4 05.1998 - 09.2001 90KW/122PS 8140.43
FIAT DUCATO Box (230L) 2.8 TDI 10.1997 - 04.2002 90KW/122PS 8140.43
FIAT DUCATO Box (230L) 2.8 TDI 4x4 06.1999 - 04.2002 90KW/122PS 8140.43
FIAT DUCATO Box (244) 2.8 TD 12.2001 - 07.2006 90KW/122PS 8140.43
FIAT DUCATO Box (244) 2.8 TD 4x4 11.2003 - 07.2006 90KW/122PS 8140.43
FIAT DUCATO Bus (230) 2.8 TDI 10.1997 - 04.2002 90KW/122PS 8140.43
FIAT DUCATO Bus (230) 2.8 TDI 4x4 07.1999 - 04.2002 90KW/122PS 8140.43
FIAT DUCATO Bus (244, Z_) 2.8 TD 11.2003 - 07.2006 90KW/122PS 8140.43
FIAT DUCATO Bus (244, Z_) 2.8 TD 4x4 11.2003 - 07.2006 90KW/122PS 8140.43
FIAT DUCATO Platform/Chassis (230) 2.8 iDTD 4x4 05.1998 - 09.2001 90KW/122PS 8140.43
FIAT DUCATO Platform/Chassis (230) 2.8 TDI 12.1998 - 04.2002 90KW/122PS 8140.43
FIAT DUCATO Platform/Chassis (244) 2.8 JTD 11.2003 - 07.2006 90KW/122PS 8140.43
FIAT DUCATO Platform/Chassis (244) 2.8 JTD 4x4 11.2003 - 07.2006 90KW/122PS 8140.43
IVECO DAILY II Box Body / Estate 2.8 4x4 02.1995 - 05.1999 90KW/122PS 8140.43.
IVECO DAILY II Box Body / Estate 30-10 01.1997 - 05.1999 76KW/103PS 8140.23
IVECO DAILY II Box Body / Estate 30-10 C 01.1997 - 05.1999 76KW/103PS 8140.23
IVECO DAILY II Box Body / Estate 35-10 (15034111, 15034204, 15034211, 15034215, 15034217,... 01.1996 - 05.1999 76KW/103PS 8140.23
IVECO DAILY II Box Body / Estate 35-12 02.1995 - 05.1999 90KW/122PS 8140.43.
IVECO DAILY II Box Body / Estate 40-10 4x4 (15214104, 15214111, 15214117, 15215111) 01.1997 - 05.1999 76KW/103PS 8140.23
IVECO DAILY II Box Body / Estate 49-10 (15054204, 15054211, 15054215, 15054217, 15054224,... 01.1996 - 12.1999 76KW/103PS 8140.23
IVECO DAILY II Box Body / Estate 49-12 V (15154204, 15154211, 15154215, 15154217,... 05.1996 - 05.1999 90KW/122PS 8140.43.
IVECO DAILY II Box Body / Estate 59-12 V (15174404, 15174411, 15174415, 15174417) 05.1996 - 05.1999 90KW/122PS 8140.43.
IVECO DAILY II Bus A 40-10 (95719111, 95719131, 95719311, 95719315,... 09.1996 - 05.1999 76KW/103PS 8140.23
IVECO DAILY II Bus A 40-12 (95819311, 95819315, 95819317, 95819331) 05.1996 - 05.1999 90KW/122PS 8140.43.
IVECO DAILY II Bus A 45-10 (95739111, 95739131, 95739311, 95739317,... 05.1996 - 05.1999 76KW/103PS 8140.23
IVECO DAILY II Bus A 45-12 (95839211, 95839231, 95839311, 95839317,... 05.1996 - 05.1999 90KW/122PS 8140.43.
IVECO DAILY II Dumptruck 35-12 K (15130311, 15130411, 15131111, 15131204,... 09.1996 - 08.1998 90KW/122PS 8140.43.
IVECO DAILY II Platform/Chassis 30-10 (15011131, 15011231) 01.1998 - 05.1999 76KW/103PS 8140.23
IVECO DAILY II Platform/Chassis 35-10 (15030111, 15030211, 15030311, 15031111, 15031117,... 01.1996 - 05.1999 76KW/103PS 8140.23
IVECO DAILY II Platform/Chassis 35-12 (15130311, 15130411, 15131111, 15131204, 15131211,... 05.1996 - 05.1999 90KW/122PS 8140.43.
IVECO DAILY II Platform/Chassis 40-10 W 4x4 (15211104, 15211105, 15211111, 15211115,... 01.1997 - 05.1999 76KW/103PS 8140.23
IVECO DAILY II Platform/Chassis 49-10 (15050304, 15050404, 15050411, 15051204, 15051211,... 05.1996 - 05.1999 76KW/103PS 8140.23
IVECO DAILY II Platform/Chassis 49-12 (15150211, 15150311, 15150404, 15150411, 15151204,... 05.1996 - 05.1999 90KW/122PS 8140.43.
IVECO DAILY II Platform/Chassis 59-12 (15170211, 15170304, 15170311, 15170504, 15170511,... 05.1996 - 05.1999 90KW/122PS 8140.43.
IVECO DAILY III Box Body / Estate 2.8 D 06.2000 - 05.2007 76KW/103PS 8140.23
IVECO DAILY III Box Body / Estate 2.8 D HM 4180 06.2000 - 07.2007 90KW/122PS 8140.43.
IVECO DAILY III Box Body / Estate 29 L 11 V 05.1999 - 07.2007 78KW/106PS 8140.43C
IVECO DAILY III Box Body / Estate 35 S 11 V,35 C 11 V 05.1999 - 07.2007 78KW/106PS 8140.43C
IVECO DAILY III Box Body / Estate 50 C 11 05.1999 - 07.2007 78KW/106PS 8140.43C
IVECO DAILY III Bus 40 C 11, 50 C 11 05.1999 - 05.2006 78KW/106PS 8140.43C
IVECO DAILY III Platform/Chassis 29 L 11 05.1999 - 04.2006 78KW/105PS 8140.43C
IVECO DAILY III Platform/Chassis 35 S 11,35 C 11 (A2FC13AA, A6FBU4AB, A2NB14A1, A2ND13A1,... 05.1999 - 04.2006 78KW/106PS 8140.43C
IVECO DAILY III Platform/Chassis 40 C 11 04.2001 - 11.2003 78KW/106PS 8140.43C
IVECO DAILY III Platform/Chassis 50 C 11 05.1999 - 04.2006 78KW/106PS 8140.43C
IVECO Power Daily II Minibus A36.10 12.2007 - ... 74KW/101PS 8140.43C
IVECO Power Daily II Minibus A40.12, A42.12, A50.12 12.2007 - ... 90KW/122PS 8140.43.
IVECO Power Daily II Platform / Chassis 42.12, 50.12 12.2007 - ... 90KW/122PS 8140.43.
OPEL Movano Minibus (X70) 2.8 DTI (JD) 07.1998 - 10.2001 84KW/114PS S9W 702
OPEL Movano Platform / Chassis (X70) 2.8 DTI (ED, HD, UD0, UD4) 07.1998 - 10.2001 84KW/114PS S9W 702
OPEL Movano Van (X70) 2.8 DTI (FD) 01.1999 - 10.2001 84KW/114PS S9W 702
PEUGEOT BOXER Box (230L) 2.8 DTiC 10.1997 - 09.2000 90KW/122PS 8140.43 (F28DT)
PEUGEOT BOXER Bus (230P) 2.8 DTiC 10.1997 - 09.2000 90KW/122PS 8140.43 (F28DT)
PEUGEOT BOXER Platform/Chassis (244) 2.8 TD 12.2001 - 03.2005 90KW/122PS 8140.43 (F28DT)
RENAULT MASTER II Box (FD) 2.8 dTI 07.1998 - 10.2001 84KW/114PS S9W 702
RENAULT MASTER II Bus (JD) 2.8 dTI 07.1998 - 10.2001 84KW/114PS S9W 702
RENAULT MASTER II Platform/Chassis (ED/HD/UD) 2.8 dTI 07.1998 - 10.2001 84KW/114PS S9W 702
VAUXHALL Movano Mk I (A) Combi (X70) 2.8 DTI (JD) 10.1998 - 10.2001 84KW/114PS S9W 702
VAUXHALL Movano Mk I (A) Van (X70) 2.8 TDI (FD) 10.1998 - 10.2001 84KW/114PS S9W 702
VAUXHALL Movano Mk1 (A) Platform / Chassis (X70) 2.8 DTI (UD0, ED, HD) 10.1998 - 10.2001 84KW/114PS S9W 702
SANTANA PS10 / Anibal Pickup 2.8 TD 12.2002 - 02.2011 78KW/106PS 8140.43C
RENAULT TRUCKS Mascott Box Body / Estate 110.35 01.1999 - 06.2004 78KW/106PS 8140.43.C.2586
RENAULT TRUCKS Mascott Box Body / Estate 110.50 01.1999 - 06.2004 78KW/106PS 8140.43.C.2586
RENAULT TRUCKS Mascott Box Body / Estate 110.55 01.1999 - 06.2004 78KW/106PS 8140.43.C.2586
RENAULT TRUCKS Mascott Dumptruck 110 01.2000 - 06.2004 78KW/106PS 8140.43.C.2586
RENAULT TRUCKS Mascott Dumptruck 90 01.2000 - 06.2004 78KW/106PS 8140.43.C.2586
RENAULT TRUCKS MASCOTT Platform/Chassis 110 01.1999 - 06.2004 78KW/106PS 8140.43.C.2586
RENAULT TRUCKS Messenger Box Body / Estate B 120.35 09.1996 - 06.1999 90KW/122PS 8140.43.2585
RENAULT TRUCKS Messenger Box Body / Estate B 120.55 (FN60F7) 09.1996 - 06.1999 90KW/122PS 8140.43.2585
RENAULT TRUCKS Messenger Platform / Chassis B 120.35 (FN40B7) 09.1996 - 06.1999 90KW/122PS 8140.43.2585
RENAULT TRUCKS Messenger Platform / Chassis B 120.55 (FN60F7) 09.1996 - 06.1999 90KW/122PS 8140.43.2585
RENAULT TRUCKS Messenger Platform / Chassis B 120.65 (FN60F8) 09.1996 - 06.1999 90KW/122PS 8140.43.2585
RENAULT TRUCKS Messenger Truck Tractor B 120.55T (FN60F7) 09.1996 - 06.1999 90KW/122PS 8140.43.2585
