MAHLE ORIGINAL Piston buy cheap at Rexbo
Piston with piston ring carrier, with cooling duct MAHLE ORIGINAL 2503001370762

MAHLE ORIGINAL 007 PI 00102 002 Piston with piston ring carrier, with cooling duct
Article number: 007 PI 00102 002

Piston 2503001370762: rating
Reviews (0)
  • Cylinder Bore [mm]: 96,2
  • Length [mm]: 93,5
  • Compression Height [mm]: 63
  • Bolt Length [mm]: 81
  • Bolt Head Diameter [mm]: 36
  • Recess Depth 1 [mm]: 16
  • Recess Diameter [mm]: 68
  • Machined: with cut-out for oil jet
  • Surface: Coated
  • Supplementary Article / Supplementary Info Info 2: with piston ring carrier, with cooling duct
  • Top Land Height [mm]: 9
  • Connecting Rod Design: Trapezoidal Connecting Rod
  • Production Number: 95 L 108
  • Component Number: 1. ET 2.5 CrK, 2. M 2.0, 3. DSF2.5 Crk P
  • Piston Clearance [mm]: 0,09
  • Packaging length [cm]: 11,6
  • Packaging width [cm]: 11,60
  • Packaging height [cm]: 14,30
  • Net Weight [g]: 1485
  • Condition: New
£ 245,87
incl. 20% VAT ,
delivery costs
Сurrently out of stock
- +
Add to basket
Facebook
Product details
  • Recess Diameter [mm]: 68
  • Recess Depth 1 [mm]: 16
  • Compression Height [mm]: 63
  • Length [mm]: 93.5
  • Cylinder Bore [mm]: 96.2
  • Supplementary Article/Supplementary Info: 139
  • Other details
  • Manufacturer: MAHLE ORIGINAL
  • Type: Piston
  • EAN: 2503001370762
MAHLE ORIGINAL 2503001370762

MAHLE ORIGINAL Piston 2503001370762 fits the following vehicles:

Manufacturer/Model/Type Year of Construction Motor Engine code Restriction
CITROËN JUMPER Box 3.0 HDi 07.2010 - 12.2013 107KW/146PS F30DTE (F1CE3481N)
CITROËN JUMPER Platform/Chassis 3.0 HDi 07.2010 - 12.2013 107KW/146PS F30DTE (F1CE3481N)
FIAT Ducato Minibus (250_, 290_) 150 Multijet 3,0 D 04.2010 - ... 107KW/146PS F1CE3481N
FIAT Ducato Minibus (250_, 290_) 160 Multijet 3,0 D 07.2006 - ... 116KW/158PS F1CE3481M
FIAT Ducato Minibus (250_, 290_) 160 Multijet 3,0 D 4x4 07.2006 - ... 116KW/158PS F1CE3481M
FIAT Ducato Minibus (250_, 290_) 180 Multijet 3,0 D 06.2011 - ... 130KW/177PS F1CE3481E
FIAT Ducato Platform / Chassis (250_, 290_) 150 Multijet 3,0 D 04.2010 - ... 107KW/146PS F1CE3481N
FIAT Ducato Platform / Chassis (250_, 290_) 160 Multijet 3,0 D 07.2006 - 12.2011 115KW/156PS F1CE3481M
FIAT Ducato Platform / Chassis (250_, 290_) 180 Multijet 3,0 D 06.2011 - ... 130KW/177PS F1CE3481E
FIAT Ducato Van (250_, 290_) 150 Multijet 3,0 D 04.2010 - ... 107KW/146PS F1CE3481N
FIAT Ducato Van (250_, 290_) 160 Multijet 3,0 D 07.2006 - 12.2011 115KW/156PS F1CE3481M
FIAT Ducato Van (250_, 290_) 160 Multijet 3,0 D 4x4 07.2006 - ... 116KW/158PS F1CE3481M
FIAT Ducato Van (250_, 290_) 180 Multijet 3,0 D 06.2011 - ... 130KW/177PS F1CE3481E
IVECO Daily Citys Minibus 40C15, 50C15, 60C15 03.2014 - ... 107KW/146PS F1CFL411E
IVECO DAILY IV Box Body / Estate 35C14 V, 35C14 V/P, 35S14 V, 35S14 V/P 09.2009 - 08.2011 103KW/140PS F1CE3481L
IVECO DAILY IV Box Body / Estate 35C17 V, 35C17 V/P, 35S17 V, 35S17 V/P 07.2007 - 08.2011 125KW/170PS F1CE3481C
IVECO DAILY IV Box Body / Estate 40C14 V, 40C14 V/P 09.2009 - 08.2011 103KW/140PS F1CE3481L
IVECO DAILY IV Box Body / Estate 40C17 V, 40C17 V/P 07.2007 - 08.2011 125KW/170PS F1CE3481C
IVECO DAILY IV Box Body / Estate 45C17 V, 45C17 V/P 07.2007 - 08.2011 125KW/170PS F1CE3481C
IVECO DAILY IV Box Body / Estate 50C14 V, 50C14 V/P 09.2009 - 08.2011 103KW/140PS F1CE3481L
IVECO DAILY IV Box Body / Estate 50C17 V, 50C17 V/P 07.2007 - 08.2011 125KW/170PS F1CE3481C
IVECO DAILY IV Box Body / Estate 60C17 V, 60C17 V/P 07.2007 - 08.2011 125KW/170PS F1CE3481C
IVECO DAILY IV Box Body / Estate 65C14 V, 65C14 V/P 09.2009 - 08.2011 103KW/140PS F1CE3481L
IVECO DAILY IV Box Body / Estate 65C17 V, 65C17 V/P 07.2007 - 08.2011 125KW/170PS F1CE3481C
IVECO DAILY IV Box Body / Estate 70C14 V, 70C14 V/P 09.2009 - 08.2011 103KW/140PS F1CE3481L
IVECO DAILY IV Box Body / Estate 70C17V, 70C17 V/P 07.2007 - 08.2011 125KW/170PS F1CE3481C
IVECO Daily IV Platform / Chassis 35C14, 35C14 /P, 35S14, 35S14 /P, 35S14 D, 35S14 D/P 09.2009 - 08.2011 103KW/140PS F1CE3481L
IVECO Daily IV Platform / Chassis 35C17, 35C17 /P, 35S17, 35S17 /P, 35S17 D 07.2007 - 08.2011 125KW/170PS F1CE3481C
IVECO Daily IV Platform / Chassis 35S17 W, 35S17 WD 07.2007 - 08.2011 125KW/170PS F1CE3481C
IVECO Daily IV Platform / Chassis 40C14, 40C14 /P 09.2009 - 08.2011 103KW/140PS F1CE3481L
IVECO Daily IV Platform / Chassis 40C17, 40C17 /P 07.2007 - 08.2011 125KW/170PS F1CE3481C
IVECO Daily IV Platform / Chassis 45C14, 45C14 /P 09.2009 - 08.2011 103KW/140PS F1CE3481L
IVECO Daily IV Platform / Chassis 45C17, 45C17 /P 07.2007 - 08.2011 125KW/170PS F1CE3481C
IVECO Daily IV Platform / Chassis 50C14, 50C14 /P 09.2009 - 08.2011 103KW/140PS F1CE3481L
IVECO Daily IV Platform / Chassis 50C17, 50C17 /P 07.2007 - 08.2011 125KW/170PS F1CE3481C
IVECO Daily IV Platform / Chassis 55S17 W, 55S17 WD 07.2007 - 08.2011 125KW/170PS F1CE3481C
IVECO Daily IV Platform / Chassis 60C14, 60C14 /P 09.2009 - 08.2011 103KW/140PS F1CE3481L
IVECO Daily IV Platform / Chassis 60C17, 60C17 /P 07.2007 - 08.2011 125KW/170PS F1CE3481C
IVECO Daily IV Platform / Chassis 65C14, 65C14 /P 09.2009 - 08.2011 103KW/140PS F1CE3481L
IVECO Daily IV Platform / Chassis 65C17, 65C17 /P 07.2007 - 08.2011 125KW/170PS F1CE3481C
IVECO Daily IV Platform / Chassis 70C14, 70C14 /P 09.2009 - 08.2011 103KW/140PS F1CE3481L
IVECO Daily IV Platform / Chassis 70C17, 70C17 /P 07.2007 - 08.2011 125KW/170PS F1CE3481C
IVECO DAILY V Box Body / Estate 35C15 V, 40C15 V, 45C15 V, 50C15 V, 60C15 V,65C15 V 09.2011 - 02.2014 107KW/146PS F1CE3481B
IVECO DAILY V Box Body / Estate 35C17, 35S17, 40C17, 45C17, 50C17, 60C17, 65C17, 70C17 09.2011 - 02.2014 125KW/170PS F1CE3481C
IVECO DAILY V Box Body / Estate 35C21 V, 35S21 V, 40C21 V, 45C21 V, 50C21 V 09.2011 - 02.2014 150KW/204PS F1CE3481D
IVECO DAILY V Box Body / Estate 35S14 04.2012 - 02.2014 110KW/150PS F1CE3481L
IVECO Daily V Minibus 35S17, 40C17, 45C17, 50C17 09.2011 - 02.2014 125KW/170PS F1CE3481C
IVECO DAILY V Platform/Chassis 35C15, 35S15, 40C15, 45C15, 50C15, 60C15, 65C15, 70C15 09.2011 - 02.2014 107KW/146PS F1CE3481B
IVECO DAILY V Platform/Chassis 35C17, 35S17, 40C17, 45C17, 50C17, 60C17, 65C17, 70C17 09.2011 - 02.2014 125KW/170PS F1CE3481C
IVECO DAILY V Platform/Chassis 35C21, 35S21, 40C21, 45C21, 50C21, 60C21, 65C21, 70C21 09.2011 - 02.2014 150KW/205PS F1CE3481D
IVECO DAILY V Platform/Chassis 55S17W 4x4 09.2011 - 02.2014 125KW/170PS F1CE3481C
IVECO DAILY VI Platform/Chassis 35S14, 35S15, 35C15, 40S14, 40C15, 50C15, 60C5, 65C15,... 03.2014 - ... 107KW/146PS F1CFL411E
IVECO DAILY VI Platform/Chassis 35S15, 55S15, 70S15, 70C15 03.2014 - ... 107KW/146PS F1CE0489EIII
IVECO DAILY VI Platform/Chassis 35S17, 35C17, 40C17, 45S17,45C17, 50C17, 60C17, 65C17,... 03.2014 - ... 125KW/170PS F1CFL411H
IVECO DAILY VI Platform/Chassis 35S21, 35C21, 40C21, 50C21, 60C21, 65C21, 70C21 03.2014 - ... 150KW/205PS F1CFL411G
IVECO DAILY VI Platform/Chassis 45-170 01.2020 - ... 125KW/170PS F1CFL411F
IVECO DAILY VI Platform/Chassis 55-170 01.2020 - ... 125KW/170PS F1CE3481C
IVECO DAILY VI Platform/Chassis 65-170 01.2020 - ... 125KW/170PS F1CE3481C
IVECO DAILY VI Platform/Chassis 70-170 03.2020 - ... 125KW/170PS F1CE3481C
IVECO Daily VI Van 35S15, 35C15, 40C15, 45C15, 50C15, 65C15, 70C15 03.2014 - 04.2016 107KW/146PS F1CFL411E
IVECO Daily VI Van 35S17, 35C17, 40C17, 50C17, 55C17, 60C17, 65C17, 70C17 03.2014 - 04.2016 125KW/170PS F1CFL411H
IVECO Daily VI Van 35S21, 35C21, 40C21, 50C21, 65C21, 70C21 03.2014 - ... 150KW/205PS F1CFL411G
IVECO Daily VI Van 45-170 Furgão 01.2020 - ... 125KW/170PS F1CE3481C
IVECO Daily VI Van 55-170 Furgão 01.2020 - ... 125KW/170PS F1CE3481C
